Standard equipment
- Supply voltage 230 V AC, 3x400 V AC
- Terminal board connection
- 2 torque switches
- 2 position switches
- 2 additional position switches
- Mechanical connection ISO 5210 - flange F10
- Space heater with thermal switch
- Mechanical position indicator
- Manual control
Additional equipment
- Supply voltage 220 V AC, 3x380 V AC
- Transmitter:
- potentiometer: 1x100 Ω, 1x2000 Ω
- electronic position transmitter 0/4 - 20 mA, (passive/active)
- CPT (capacitive) 4 - 20 mA, (passive/active)
- Mechanical connection:
- ISO 5210, shape A
- DIN 3338, shape C
- other non-standard connection
|
